Eaton / Moeller Series
90 A, 690 V, NZM2, IP20, RoHS compliant, UL listed
Eaton Moeller series NZM molded case circuit breaker thermo-magnetic, Catalog Number 269181, EAN 4015082691813, designed for North America, with a rated operational current of 90 A and a voltage rating of 690 V. It complies with RoHS and is certified by CE, CSA, and UL.
Country of Origin: DE
We source directly from Eaton - 100% genuine, new-in-box certified parts.
| Specification | Value |
|---|---|
| Product Name | Eaton Moeller series NZM molded case circuit breaker thermo-magnetic |
| Catalog Number | 269181 |
| EAN | 4015082691813 |
| Model Code | NZMN2-AF90-NA |
| Compliance | RoHS conform |
| Certifications | CE marking, CSA-C22.2 No. 5-09, UL listed, IEC/EN 60947 |
| Mounting Method | Built-in device fixed built-in technique, DIN rail mounting optional |
| Handle Type | Rocker lever |
| Rated Insulation Voltage | 1000 V AC |
| Specification | Value |
|---|---|
| Amperage Rating | 90 A |
| Voltage Rating | 690 V - 690 V |
| Circuit Breaker Frame Type | NZM2 |
| Temperature Rise | Panel builder's responsibility |
| Short-Circuit Rating | Panel builder's responsibility |
| Electromagnetic Compatibility | Panel builder's responsibility |
| Mechanical Function | Meets requirements |
| Corrosion Resistance | Meets requirements |
| Protection Against Electric Shock | Does not apply |
| Pollution Degree | 3 |
| Climatic Proofing | Damp heat, constant, to IEC 60068-2-78 |
| Degree of Protection | IP20 |
| Rated Operational Current | 300 A (380/400 V AC-1) |
| Short-Circuit Total Breaktime | < 10 ms |
| Rated Short-Circuit Breaking Capacity | 85 kA at 230 V |
