Eaton / Moeller Series
Undervoltage release, 24 VDC
Eaton Moeller series NZM Undervoltage release, 24 V DC, for NZM1, L. Catalog Number: 259481, Model Code: NZM1-XUL24DC, EAN: 4015082594817. Complies with UL/CSA, IEC, RoHS standards. Certified by CSA, IEC60947, and UL.
Country of Origin: DE
We source directly from Eaton - 100% genuine, new-in-box certified parts.
| Specification | Value |
|---|---|
| Product Name | Eaton Moeller series NZM Undervoltage release |
| Catalog Number | 259481 |
| Model Code | NZM1-XUL24DC |
| EAN | 4015082594817 |
| Compliance | UL/CSA, IEC, RoHS conform |
| Certifications | CSA (Class No. 1437-01), IEC60947, UL (File No. E140305), CE marking |
| Frame | NZM1 |
| Suitable For | Off-load switch |
| Specification | Value |
|---|---|
| Rated Control Supply Voltage | 24 V DC |
| Pick-Up Power Consumption at AC | 1.5 VA |
| Pick-Up Power Consumption at DC | 0.8 W |
| Drop-Out Voltage of Undervoltage Release (AC/DC - MAX) | 0.7 x Us |
| Drop-Out Voltage of Undervoltage Release (AC/DC - MIN) | 0.35 x Us |
| Minimum Command Time - MAX | 15 ms |
| Minimum Command Time - MIN | 10 ms |
| Reaction Time | 19 ms |
| Terminal Capacity (Solid/Flexible Conductor) | 18 - 14 AWG (1x) at shunt release |
