Eaton / Moeller Series
1.5A, 1P, D-Curve, UL 489, DIN rail breaker, ring-tongue terminals
The Eaton/Moeller FAZ-D1.5/1-RT-SP is a single-pole, 1.5 amp D-curve miniature circuit breaker designed for branch circuit protection in high inrush applications. Featuring ring-tongue terminals and a compact 17.7 mm width, it is UL 489 listed and CSA certified (C22.2 No.5-02). This breaker offers a 10 kAIC interrupting capacity (UL/CSA) and up to 14 kAIC for select amperages per IEC 60947-2. The D-curve trip characteristic (10–20× In) is ideal for inductive loads such as motors and transformers.
Country of Origin: DE
We source directly from Eaton - 100% genuine, new-in-box certified parts.
| Brand | Eaton / Moeller |
|---|---|
| Model | FAZ-D1.5/1-RT-SP |
| Alternate Part Number | WMZT1DX1T (Obsolete) |
| Series | FAZ-RT |
| Product Type | Miniature Circuit Breaker (MCB) |
| Mounting | DIN Rail |
| Terminal Type | Ring-Tongue |
| Packaging | Single-Pack (SP) |
| Standards | UL 489, CSA C22.2 No.5-02, IEC 60947-2 |
| UL File Number | E235139 |
| Amperage | 1.5A |
|---|---|
| Poles | 1 |
| Trip Type | Thermal-Magnetic |
| Curve Type | D-Curve (10–20× In) |
| Interrupting Capacity | 10 kAIC (UL/CSA), 14 kAIC (IEC) |
| Voltage Rating | 277/480V AC, 125V DC per pole |
| Current Limiting | Yes |
| SWD Rating | Yes (≤ 20A) |
| Trip-Free Mechanism | Yes |
| Module Width | 17.7 mm |
| Contact Position Indicator | Yes (Red/Green) |
| Field Installable Options | Shunt Trip, Auxiliary Switch |
| Sealable Toggle | Yes (ON/OFF positions) |
| Typical Applications | Motors, Transformers, Control Circuits, UPS, Power Supplies |
