Eaton / Moeller Series
1 early N/O + 1 late N/C, position switch, roller plunger, slow action, IP65, IEC/EN
The Eaton Moeller AT0-11-2-IA/RS is a wide-enclosure position switch featuring a roller plunger actuator with one early-make normally open (N/O) and one late-break normally closed (N/C) contact. Designed for precision and durability, it offers slow-action switching, IP65 protection, and a robust insulated plastic housing. With a mechanical lifespan of up to 20 million operations and positive opening to IEC/EN 60947-5-1 standards, it is suitable for safety and automation applications. The actuator head can rotate 90° for flexible mounting, and screw terminal connections ensure secure wiring.
Country of Origin: DE
We source directly from Eaton - 100% genuine, new-in-box certified parts.
| Brand | Eaton Moeller |
|---|---|
| Model | AT0-11-2-IA/RS |
| Catalog Number | 085902 |
| Product Type | Position Switch |
| Series | AT0 |
| Actuator Type | Roller Plunger |
| Contact Configuration | 1 Early N/O + 1 Late N/C |
| Action Type | Slow Action |
| Design Standard | EN 50047 Form C |
| Mounting Position | As required (head rotatable 90°) |
| Connection Type | Screw Terminal |
| Enclosure Material | Insulated Plastic Housing |
| Enclosure Color | Grey |
| Degree of Protection | IP65 |
| Mechanical Life | 20 × 10⁶ operations |
| Positive Opening | Yes (IEC/EN 60947-5-1) |
| Suitable for Safety Functions | Yes |
| Operating Temperature Range | −25 °C to +70 °C |
| Rated Insulation Voltage (Ui) | 500 V AC |
|---|---|
| Rated Impulse Withstand Voltage (Uimp) | 6 kV |
| Rated Operational Current (AC-15 / 24 V) | 10 A |
| Rated Operational Current (AC-15 / 230 V) | 6 A |
| Rated Operational Current (AC-15 / 415 V) | 4 A |
| Rated Operational Current (DC-13 / 24 V) | 10 A |
| Rated Operational Current (DC-13 / 110 V) | 1 A |
| Rated Operational Current (DC-13 / 220 V) | 0.5 A |
| Short-Circuit Protection | 6 A gG/gL fuse (max) |
| Repetition Accuracy | 0.02 mm |
| Actuating Force | 1.0 N (start) / 8.0 N (end) |
| Actuating Torque | 0.2 Nm |
| Max. Operating Speed (DIN cam) | 1 m/s |
| Operating Frequency | ≤ 6000 operations/h |
| Supply Frequency | Max 400 Hz |
| Terminal Capacity (Solid) | 1 × (0.75–2.5 mm²) / 2 × (0.75–1.5 mm²) |
| Terminal Capacity (Flexible w/ Ferrule) | 1 × (0.5–1.5 mm²) / 2 × (0.5–1.5 mm²) |
| Mechanical Shock Resistance | 25 g (standard action) |
| Compliance Standards | IEC/EN 60947, EN 50047 Form C, IEC 60068-2-78 / -2-30 |
