Eaton / Moeller Series
2NC, position switch, angled roller lever, IP65, IEC
The Eaton AT0-02-1-IA/AR is a position switch featuring two normally closed (2NC) contacts with positive opening operation for reliable safety performance. It is equipped with an angled roller lever actuator designed for precise mechanical detection and smooth operation. The unit features a wide, insulated plastic housing and is rated IP65, ensuring high protection against dust and water ingress. Built to comply with IEC/EN 60947-5-1 standards, this switch provides dependable functionality in industrial automation, machinery safety, and limit detection applications.
Country of Origin: DE
We source directly from Eaton - 100% genuine, new-in-box certified parts.
| Brand | Eaton |
|---|---|
| Model | AT0-02-1-IA/AR |
| Catalog Number | 005222 |
| Product Type | Position Switch |
| Actuator Type | Angled Roller Lever |
| Contact Configuration | 2NC |
| Contact Type | Slow-action (Positive Opening) |
| Enclosure Material | Insulated Plastic |
| Housing Version | Wide |
| Mounting Position | Any |
| Degree of Protection | IP65 |
|---|---|
| Rated Insulation Voltage (Ui) | 500 V |
| Impulse Withstand Voltage (Uimp) | 6 kV |
| Rated Operational Current (AC-15) | 6 A @ 230 V AC |
| Rated Operational Current (DC-13) | 10 A @ 24 V DC |
| Thermal Current (Ith) | 10 A |
| Short-Circuit Protection | 6 A gG/gL Fuse |
| Mechanical Life | 20 × 10⁶ operations |
| Repetition Accuracy | 0.02 mm |
| Operating Frequency | ≤ 6000 operations/hour |
| Actuation Torque | 0.2 Nm |
| Operating Speed (DIN Cam) | 1 m/s |
| Ambient Temperature Range | −25 °C to +70 °C |
| Standards Compliance | IEC/EN 60947-5-1, IEC 60068 |
| Certifications | CE |
