Eaton / Moeller Series
25A, 3P, control panel bus adapter, busbar mount with 20×5 mm Cu bar and 60 mm phase separation, IEC/UL/CSA compliant
The Moeller AD25/5-2 is a 3-pole control panel bus adapter designed for mounting in industrial control panels onto copper busbars of 20 × 5 mm with 60 mm phase separation. Rated for 25 A with 10 AWG supply leads and a 108 mm adapter width, it accommodates multiple configurations: two PKZM0 or PKZM0-/S(E)00 units; two PKZM0-/S(E)00 units with AGM or NHI accessories; or one PKZM0 with two EZ-PKZ0 plus MV-PKZ0 modules. The adapter attaches directly to the bus at the rear while devices mount on top, with wiring to the supply leads. Assembly must always be carried out under de-energized (power-off) conditions for safety.
Country of Origin: DE
We source directly from Eaton - 100% genuine, new-in-box certified parts.
| Brand | Moeller |
|---|---|
| Product Name | Control Panel Bus Adapter |
| Model | AD25/5-2 |
| Article Number | AD25/5-2 |
| Product Type | Bus Adapter, 3-Pole |
| For Use With | 2 × PKZM0 or PKZM0-/S(E)00 2 × PKZM0-/S(E)00 + AGM or NHI 1 × PKZM0 + 2 × EZ-PKZ0 + MV-PKZ0 |
| Adapter Width | 108 mm |
| Mounting | Cu busbar 20 × 5 mm, 60 mm phase separation |
| Included | 1 × AD25/5-2 Control Panel Bus Adapter |
| Maximum Rated Current | 25 A |
|---|---|
| Adapter Supply Leads | 10 AWG |
| Number of Poles | 3 |
| Connection Type | Rear bus connection with top-mounted devices |
| Operating Condition | Installation under de-energized (power-off) conditions |
| Certifications | IEC/EN, UL, CSA compliant |
