| PART # | CONTACTOR FOR USE ON | DESCRIPTION | FUNCTION |
|---|---|---|---|
| DILM400-XS1 | DILM185-DILM400 |
STAR BRIDGE
|
SOLID JUMPER THAT CONNECTS ALL 3 POWER POLES TOGETHER. HAS NO INCOMING WIRE TERMINAL CONNECTIONS. |
| DILM500-XS1 |
|
||
| DILM185-XP1 | DILM185 |
PARALLELING BRIDGE
|
SOLID JUMPER THAT CONNECTS ALL 3 POWER POLES TOGETHER AND HAS A SINGLE INCOMING TERMINAL CONNECTION. |
| BT480 | All top mounting auxiliary contacts | Paralleling Links | Not insulated. Standard Quantity: 100 |
| DILM500-XMV | DILM185, DILM225,DILM250, DILM300, DILM400,DILM500 | MECHANICAL INTERLOCK KIT | For providing mechanical interlock between 2 contactors. No side mount auxiliary contacts may be used except on the opposite sides of the MV module. |
| DILM820-XMV | DILM580, DILM650, DILM758, DILM820 | ||
| DILM225-XKU-S | DILM185, DILM225 | Cable Terminal Block with control circuit terminal |
For cable connection. Single or double
cables may be
connected. |
| DILM400-XKU-S | DILM250, DILM300, DILM400 | ||
| DILM650-XKB-S | DILM500, DILM580, DILM650 | Flat Strip Conductor Terminal Kit | For bus and flexibus connection. |
| DILM820-XKB-S | DILM750, DILM820 | ||
| DILM400-XHB | DILM185, DILM225, DILM250, DILM300, DILM400 | Terminal Cover | Protection against shock hazards and accidental contact |
| DILM500-XHB | DILM500 | ||
| DILM650-XHB | DILM580, DILM650 | ||
| DILM820-XHB | DILM750, DILM820 | ||
| CS-TE | ETS4-VS3 |
Coupling
Connector |
For screw mounting of ETS4-VS3 |
| XGKA-U | Universal Mounting Adapter |
Mounting:
|
|
| ETS4-VS3 |
Any Contactor
with less than 2 amp coil |
SEPARATE
DIN RAIL MOUNT |
For energizing of the contactor from low level 24 vdc inputs. |
