Eaton / Moeller Series
10–16A relay for DIL contactors
Moeller Z00-16 thermal overload relay, designed for direct mounting on DIL00M or DIL0M series contactors. Features an adjustable setting range of 10 to 16A, with one normally open and one normally closed contact. Offers short circuit protection via fuses or circuit breakers rated at 60A, up to 600V AC. Provides phase-failure sensitivity per IEC/EN 60947. UL listed (E29184) and CSA certified (45958, 43359).
Country of Origin: DE
We source directly from Eaton - 100% genuine, new-in-box certified parts.
| Model | Z00-16 |
|---|---|
| Device Type | Thermal Overload Relay |
| Mounting | Direct Mount on DIL00M / DIL0M Contactors |
| Adjustable Setting Range | 10 - 16A |
| Normally Open Contacts | 1 |
| Normally Closed Contacts | 1 |
| Short Circuit Protection (Fuses) | 60A @ 600V AC |
| Short Circuit Protection (Breaker) | 60A @ 600V AC |
| Phase-Failure Sensitivity | IEC/EN 60947 |
| Certifications | UL (E29184), CSA (45958, 43359) |
