Eaton / Moeller Series
0.4–0.6A thermal overload relay
The Moeller Z00-0.6 is a thermal overload relay with an adjustable current range of 0.4–0.6 A, designed for direct mounting onto DIL00M and DIL0M series contactors. It provides motor protection through a bimetallic trip mechanism and includes one normally open (NO) and one normally closed (NC) auxiliary contact. The device is UL listed, CSA certified, and compliant with IEC/EN 60947 standards. It features phase-failure sensitivity and requires external short-circuit protection via fuses or circuit breakers rated up to 600 V AC. Ideal for small motor applications and panel-mounted motor starters.
Country of Origin: DE
We source directly from Eaton - 100% genuine, new-in-box certified parts.
| Brand | Moeller |
|---|---|
| Model | Z00-0.6 |
| Product Type | Thermal Overload Relay |
| Mounting Type | Direct Mount on DIL00M / DIL0M Contactors |
| Standards | IEC/EN 60947, UL Listed (E29184), CSA Certified (45958, 43359) |
| Phase-Failure Sensitivity | Yes |
| Adjustable Current Range | 0.4 – 0.6 A |
|---|---|
| Auxiliary Contacts | 1 NO + 1 NC |
| Circuit Diagram | Z00-0.6 |
| Short Circuit Protection | Via fuses or circuit breaker (max. 600 V AC) |
| Compatibility | DIL00M, DIL0M Series Contactors |
