Eaton / Moeller Series
32A, 3P, DOL motor starter, 24 V DC control, IE3-ready, IEC/EN 60947-4-1 / VDE 0660
The Eaton XTSEA032B032CTDNL is a 32 A, 3-pole direct-on-line (DOL) motor starter designed for reliable control and protection of three-phase motors up to 15 kW at 400 V AC (18.5 kW at 500 V). It includes an integrated PKE motor-protective circuit-breaker and DILM32 contactor, providing overload protection with an adjustable release range of 8 – 32 A and a non-delayed short-circuit release at 448 A. The unit operates on a 24 V DC control voltage and is IE3 motor compatible, meeting modern energy efficiency requirements. It is rated for short-circuit currents up to 100 kA (coordination type 2) and complies with IEC/EN 60947-4-1 and VDE 0660 standards. The DOL starter supports SmartWire-DT communication with the addition of the PKE-SWD-32 module and offers IP20 protection for safe, efficient, and compact motor starting applications.
Country of Origin: DE
We source directly from Eaton - 100% genuine, new-in-box certified parts.
| Brand | Eaton |
|---|---|
| Model | XTSEA032B032CTDNL |
| Series | MSC-DE |
| Product Type | DOL Motor Starter |
| Rated Operational Current (Ie) | 32 A |
| Motor Rating (AC-3, 400 V) | 15 kW |
| Motor Rating (AC-3, 500 V) | 18.5 kW |
| Setting Range (Overload Release Ir) | 8 – 32 A |
| Trip Type | Thermal-magnetic |
| Control Voltage | 24 V DC |
| Poles | 3 |
| Coordination Type | Type 1 / Type 2 |
| Frame Size | 32 A frame (MSC series) |
| Rated Operational Voltage (Ue) | 230 – 415 V AC |
|---|---|
| Rated Impulse Withstand Voltage (Uimp) | 6 kV |
| Rated Short-Circuit Current (Iq) | 100 kA @ 400 V / 50 kA @ 500 V |
| Overvoltage Category / Pollution Degree | III / 3 |
| Wiring Type | Screw connection |
| Protection Degree | IP20 |
| Bus Communication Compatibility | SmartWire-DT (with PKE-SWD-32 module) |
| Applicable Standards | IEC/EN 60947-4-1, VDE 0660 |
| Short-Circuit Release (Irm) | 448 A (non-delayed) |
| Motor Compatibility | IE3-ready motors |
| Heat Dissipation | 0 W (nominal) |
| Mounting | Top-hat rail or adapter plate |
