Eaton / Moeller Series
12A, 3P, DOL motor starter, 24 V DC coil, screw connection, IEC/EN 60947-4-1, VDE 0660
The Eaton XTSEA012B012BTDNL DOL Motor Starter is a reliable direct-on-line starter designed for robust motor control applications up to 5.5 kW (400 V AC). It integrates a PKE12/XTU-12 motor-protective circuit-breaker with a DILM12 contactor, operating on a 24 V DC control voltage. The unit provides an adjustable overload range from 3 – 12 A, a rated operational current of 11.3 A (AC-3, 400 V), and a short-circuit withstand capacity of 100 kA. It supports IE3 high-efficiency motors, offers Type 2 coordination, and features screw-type connections and IP20 protection. Fully compliant with IEC/EN 60947-4-1 and VDE 0660, this DOL starter delivers compact installation, dependable performance, and compatibility with SmartWire-DT communication for integrated motor management systems.
Country of Origin: DE
We source directly from Eaton - 100% genuine, new-in-box certified parts.
| Brand | Eaton |
|---|---|
| Model | XTSEA012B012BTDNL |
| Series | MSC-DEA |
| Product Type | DOL Motor Starter (Complete Device) |
| Basic Device | MSC |
| Motor Rating (AC-3, 400 V) | 5.5 kW |
| Rated Operational Current (Ie) | 11.3 A (400 V) |
| Setting Range (Overload Release) | 3 – 12 A |
| Short-Circuit Release (Irm) | 168 A |
| Actuating Voltage | 24 V DC |
| Poles | 3 |
| Coordination Type | Type 2 |
| Operator | Contactor + Motor Protective Circuit-Breaker |
| Connection Type | Screw Connection |
| Rated Operational Voltage (Ue) | 230 – 415 V AC |
|---|---|
| Rated Operational Current (AC-3, 400 V) | 11.3 A |
| Rated Short-Circuit Current (Iq) | 100 kA (380–400 V) |
| Rated Impulse Withstand Voltage (Uimp) | 6 kV |
| Rated Power at AC-3, 400 V | 5.5 kW |
| Control Supply Voltage (Us, DC) | 24 V DC |
| Voltage Type for Actuating | DC |
| Overvoltage Category / Pollution Degree | III / 3 |
| Degree of Protection | IP20 |
| Coordination Type | 1 and 2 |
| Standard Compliance | IEC/EN 60947-4-1, VDE 0660 |
| Suitable for Motor Efficiency Class | IE3 Ready |
| Bus Connection Compatibility | SmartWire-DT (via PKE-SWD-32 Module) |
| Mounting | Top-hat rail, adapter-less (≤ 15 A) |
| Power Consumption (DC Sealing) | 4.5 W |
| Heat Dissipation | 0 W (nominal) |
