Eaton / Moeller Series
16 A, 3P, Manual Motor Protector, adjustable thermal 10–16 A, UL/CSA certified
The Eaton XTPR016BC1NL is a 3-pole manual motor protector designed to provide reliable protection against overloads and short circuits in motor circuits. Featuring an adjustable thermal range of 10 A to 16 A and a magnetic trip response of 224 A, it ensures precise motor protection and optimal performance. The unit supports motors rated up to 5 HP at 230 V AC and 10 HP at 460 V AC. UL Listed and CSA Certified, it complies with NEC 430-53 and CEC Rule 28-206 for group motor installations, eliminating the need for separate branch circuit protection. This reduces both installation cost and panel space, making it ideal for industrial control assemblies.
Country of Origin: DE
We source directly from Eaton - 100% genuine, new-in-box certified parts.
| Brand | Eaton |
|---|---|
| Model | XTPR016BC1NL |
| Product Type | Manual Motor Protector |
| Amperage | 16 A |
| Poles | 3 |
| Adjustable Thermal Range | 10 A – 16 A |
| Trip Type | Thermal-Magnetic |
| Operator | Manual |
| Frame Size | XTPR Series |
| Voltage Rating | Up to 600 V AC |
|---|---|
| UL/CSA Motor Rating @ 230 V | 5 HP |
| UL/CSA Motor Rating @ 460 V | 10 HP |
| Short-Circuit Current Rating | 10 kA @ 600 V AC |
| Max. Branch Circuit Protective Fuse | 150 A |
| Max. Branch Circuit Protective Breaker | 125 A |
| Magnetic Trip Response Current | 224 A |
| Certifications | UL Listed, CSA Certified |
| Compliance | NEC 430-53, CEC Part 1 Rule 28-206 |
