Eaton / Moeller Series
65A, 3P, Motor-Protective Circuit-Breaker, electronic overload & short-circuit protection, IEC/EN/VDE compliant
The Eaton XTPE065DCSSP is a 65A, 3-pole motor-protective circuit-breaker designed for reliable motor control and protection in industrial Type E DOL starter applications. It features an adjustable overload release from 16 A to 65 A and a non-delayed short-circuit release rated at 910 A, providing dependable protection for motors up to 40 HP at 480 V AC. The device offers high short-circuit ratings up to 65 kA (480 V) and 25 kA (600 V), ensuring safe performance under demanding operating conditions. Built for North American and global standards, it meets IEC/EN 60947-4-1 and VDE 0660 requirements. With IP20 protection, screw terminals, and electronic switching, the XTPE065DCSSP is an efficient, compact solution for motor circuit protection.
Country of Origin: DE
We source directly from Eaton - 100% genuine, new-in-box certified parts.
| Brand | Eaton |
|---|---|
| Model | XTPE065DCSSP |
| Series | XTPE |
| Product Type | Motor-Protective Circuit-Breaker |
| Basic Function | Type E DOL Starter (Complete Device) |
| Connection to SmartWire-DT | No |
| Rated Current (Ie) | 65 A |
| Setting Range (Overload Release Ir) | 16 – 65 A |
| Short-Circuit Release (Irm) | 910 A (Non-delayed) |
| Number of Poles | 3 |
| Operator Type | Manual |
| Frame Size | PKE65/AK/XTU-65-SP |
| Connection Type | Screw Connection |
| Degree of Protection | IP20 |
| Phase Failure Sensitivity | Yes |
| Switch-Off Technique | Electronic |
| Rated Operational Voltage (Ue) | 208 – 480 V AC |
|---|---|
| Rated Operating Voltage (ETIM) | 690 V AC |
| Rated Impulse Withstand Voltage (Uimp) | 6000 V AC |
| Overvoltage Category / Pollution Degree | III / 3 |
| Rated Short-Circuit Capacity (Icu at 400 V AC) | 80 kA |
| Short-Circuit Current Rating (240 V) | 65 kA |
| Short-Circuit Current Rating (480 V) | 65 kA |
| Short-Circuit Current Rating (600 V) | 25 kA |
| Rated Operational Power (AC-3, 230 V) | 18.5 kW / 15 HP |
| Rated Operational Power (AC-3, 400 V) | 30 kW / 40 HP |
| Rated Permanent Current (Iu) | 65 A |
| Insulation Voltage | 690 V AC |
| Heat Dissipation | 0 W (Pdiss) |
| Standards | IEC/EN 60947-4-1, VDE 0660 |
| Certifications | IEC/EN, VDE, UL (when applicable) |
