Eaton / Moeller Series
7A, 3P, 42–48 Vac coil, UL/CSA
The Eaton XTCE007B10W is a three-pole full-voltage non-reversing IEC contactor rated at 7 A and equipped with a dual-rated 42 Vac (50 Hz) / 48 Vac (60 Hz) coil. It includes one normally open auxiliary contact and uses screw terminals for secure wiring. Designed on Frame B (45 mm) within the XT IEC series, it supports motor ratings from 0.25 to 5 hp across common voltage levels. Certified to UL and CSA standards, this compact contactor is well-suited for electrical assemblies, OEM equipment, and panel applications.
Country of Origin: DE
We source directly from Eaton - 100% genuine, new-in-box certified parts.
| Brand | Eaton |
|---|---|
| Model | XTCE007B10W |
| Style Number | MSAA276546 |
| Series | XT IEC |
| Product Type | Full voltage non-reversing contactor (FVNR) |
| Amperage Rating | 7 A |
| Poles | 3 |
| Auxiliary Contacts | 1 NO |
| Coil Voltage | 42–48 Vac, 50/60 Hz |
| Operation | Non-reversing |
| Terminals | Screw terminals |
| Frame Size | Frame B (45 mm) |
| Dimensions (L×W×H) | 2 × 3 × 2.5 in |
| Weight | 0.5071 lb |
| Continuous Ampere Rating | 7 A |
|---|---|
| Coil Voltage / Frequency | 42 Vac (50 Hz) / 48 Vac (60 Hz) |
| HP Rating (Max) | 0.25, 0.75, 1/1.5, 2, 3, 5 hp (1/3Φ @115, 200, 230/200, 230, 460, 575 V) |
| Contact Configuration | 1 NO |
| Number of Poles | Three-pole |
| Wiring | Screw terminals |
| Applications | Electrical assemblies, panels, EOEM |
| Certifications | UL Listed; CSA Certified |
| EAN Number | 4015082765460 |
| Government Stocking Number | 4210 |
