Eaton / Moeller Series
7A, 3P, 110–120 Vac coil, UL/CSA/IEC
The Eaton Moeller XTCE007B01A is an XT IEC three-pole, full voltage non-reversing contactor rated 7 A with a 110–120 Vac, 50/60 Hz coil and screw terminals. It provides up to 0.25–5 hp motor ratings at 1/3PH across 115, 200, 230, 460, and 575 V systems, in a compact 45 mm frame size for non-reversing motor control applications. The device is RoHS Compliant, CE Marked, and certified to UL, CSA, IEC 60947, and EN 60947 standards.
Country of Origin: DE
We source directly from Eaton - 100% genuine, new-in-box certified parts.
| Brand | Eaton |
|---|---|
| Product Name | Eaton XT IEC contactor |
| Catalog Number | XTCE007B01A |
| EAN | 4015082765828 |
| Series | XT IEC |
| Product Type | Full voltage non-reversing contactor |
| Amperage Rating | 7 A |
| Continuous Ampere Rating | 7 A |
| Number of Poles | Three-pole |
| Contact Configuration | 1 NC |
| Operation | Non-reversing |
| Coil Voltage | 110–120 Vac, 50/60 Hz |
| Frequency Rating | 50–60 Hz |
| HP Rating - Max | 0.25, 0.75, 1 / 1.5, 2, 3, 5 hp (1/3PH @115, 200, 230 / 200, 230, 460, 575 V) |
| Frame Size | 45 mm |
| Terminals | Screw terminals |
| Product Length/Depth | 3 in |
| Product Height | 2 in |
| Product Width | 3 in |
| Product Weight | 0.5 lb |
| Coil Voltage | 110–120 Vac, 50/60 Hz |
|---|---|
| Frequency Rating | 50–60 Hz |
| Continuous Ampere Rating | 7 A |
| HP Rating - Max | 0.25, 0.75, 1 / 1.5, 2, 3, 5 hp (1/3PH @115, 200, 230 / 200, 230, 460, 575 V) |
| Number of Poles | Three-pole |
| Contact Configuration | 1 NC |
| Terminals | Screw terminals |
| Frame Size | 45 mm |
| Type | Full voltage non-reversing contactor |
| Compliances | RoHS Compliant; CE Marked |
| Certifications | UL Listed; CSA Certified; IEC 60947; EN 60947 |
