55–65A motor breaker, 50kA @ 600V
Moeller PKZM4-63 motor protection circuit breaker with screw terminal connection. Engineered for robust industrial motor applications, offering adjustable thermal overload protection from 55–65A. Rated for short-circuit currents up to 50kA at 600V, with a magnetic short-circuit release set at 882A. Compatible with high-capacity backup fuses or circuit breakers up to 600A with current limiting, providing enhanced protection and selectivity.
We source directly from Eaton - 100% genuine, new-in-box certified parts.
| Model | PKZM4-63 |
|---|---|
| Connection Type | Screw Terminal |
| Rated Operating Voltage | 600V |
| Overload Release Range | 55–65A |
| Short-Circuit Breaking Capacity | 50kA @ 600V |
| Short Circuit Release | 882A |
| Maximum Backup Fuse (CL) | 600A |
| Maximum Backup Circuit Breaker (CL) | 600A |
| Trip Type | Thermal-Magnetic |
