Eaton / Moeller Series
6A, 3P, manual motor protector, adjustable thermal/magnetic trip, UL/CSA
The Moeller PKZ2/ZM-6 is a manual motor protector that includes the PKZ2 basic module and ZM-6-PKZ2 overload module. It provides adjustable thermal protection from 4–6 A and magnetic trip protection from 50–80 A. Rated for up to 1.5 HP at 230V and 3 HP at 460V, it ensures dependable motor circuit protection in industrial environments.
Country of Origin: DE
We source directly from Eaton - 100% genuine, new-in-box certified parts.
| Brand | Moeller |
|---|---|
| Model | PKZ2/ZM-6 |
| Series | PKZ2 |
| Product Type | Manual Motor Protector |
| Included Modules | PKZ2 (Base Module), ZM-6-PKZ2 (Overload) |
| Poles | 3 |
| Trip Type | Adjustable Thermal & Magnetic |
| Amperage Range (Thermal) | 4 – 6 A |
| Magnetic Trip Setting | 50 – 80 A |
| Voltage Rating | Up to 600V AC |
|---|---|
| Horsepower Rating @ 230V | 1.5 HP (3-phase) |
| Horsepower Rating @ 460V | 3 HP (3-phase) |
| Insulation Voltage | 690V |
| Interrupting Capacity | Up to 100 kA (with appropriate backup fuse) |
| Wiring Type | Screw Terminals |
| Mounting | DIN Rail |
| Certifications | UL, CSA |
