Eaton / Moeller Series
0.6A, 3P, manual motor protector, adjustable thermal/magnetic trip, UL/CSA
The Moeller PKZ2/ZM-0.6 is a modular manual motor protector designed for motor control and protection applications. It includes the PKZ2 base module and the ZM-0.6-PKZ2 overload module, providing both thermal and magnetic protection. The thermal trip is adjustable between 0.4–0.6A to match the motor's full load current (FLC), while the magnetic trip is factory-set between 5–8A for short-circuit protection. Certified for use under UL and CSA standards, the PKZ2/ZM-0.6 offers reliable protection for motors with horsepower ratings up to 2 HP at 230V and 3 HP at 460V in 3-phase systems.
Country of Origin: DE
We source directly from Eaton - 100% genuine, new-in-box certified parts.
| Brand | Moeller |
|---|---|
| Model | PKZ2/ZM-0.6 |
| Series | PKZ2 |
| Product Type | Manual Motor Protector |
| Included Modules | PKZ2 (Base Module), ZM-0.6-PKZ2 (Overload) |
| Poles | 3 |
| Trip Type | Adjustable Thermal & Magnetic |
| Amperage Range (Thermal) | 0.4 – 0.6 A |
| Magnetic Trip Setting | 5 – 8 A |
| Voltage Rating | Up to 600V AC |
|---|---|
| Horsepower Rating @ 230V | 2 HP (3-phase) |
| Horsepower Rating @ 460V | 3 HP (3-phase) |
| Insulation Voltage | 690V |
| Interrupting Capacity | Up to 100 kA (with appropriate short-circuit backup protection) |
| Wiring Type | Screw Terminals |
| Mounting | DIN Rail |
| Certifications | UL, CSA |
