Eaton / Moeller Series
63A, 3P, main switch, emergency switching off, red/yellow lockable handle, UL/CSA
The Eaton Moeller P3-63/I4/SVB is a 3-pole, 63 A main switch (switch-disconnector) for surface mounting with an emergency switching-off function. It features a red rotary handle with a yellow locking ring that can be padlocked in the 0 (Off) position, IP65 protection, and a 90° switching angle. Rated to 690 V AC with 6 kV impulse withstand (Uimp) and overvoltage category III/3, it supports AC-23A motor duties up to 30 kW at 400/415 V. Short-circuit performance includes Icw 1.26 kA (1 s), Iq 4 kA, and SCCR 10 kA (with max 150 A fuse). Complies with IEC/EN 60947-3, IEC/EN 60204, VDE 0660; UL/CSA noted; CE declaration available. Operating ambient −25…+40 °C. Terminal capacity up to 35 mm² (AWG 14–2) with M5 screws (3 Nm / 26.5 lb-in).
We source directly from Eaton - 100% genuine, new-in-box certified parts.
| Brand | Eaton Moeller |
|---|---|
| Model | P3-63/I4/SVB |
| Catalog No. | 207343 |
| Product Type | Main switch (switch-disconnector) |
| Stop Function | Emergency switching off function |
| Design | Surface mounting |
| Operator | Red rotary handle with yellow locking ring (door-coupling rotary drive) |
| Locking Facility | Lockable in 0 (Off) position |
| Poles | 3 |
| Switching Angle | 90° |
| Degree of Protection | IP65 |
| Mounting Position | As required |
| Rated Operational Voltage (Ue) | 690 V AC |
|---|---|
| Rated Uninterrupted Current (Iu) | 63 A |
| Impulse Withstand Voltage (Uimp) | 6 kV |
| Overvoltage Category / Pollution Degree | III / 3 |
| AC-23A Motor Rating (50–60 Hz) | 30 kW @ 400/415 V; 18.5 kW @ 230 V; 45 kW @ 500 V; 55 kW @ 690 V |
| Rated Operational Current (motor load, AC-23A) | 63 A (230/400/415/500/690 V) |
| Conditional Short-Circuit Current (Iq) | 4 kA |
| Short-Time Withstand Current (Icw, 1 s) | 1.26 kA |
| SCCR (North America) | 10 kA with max 150 A fuse |
| Recommended Fuse (IEC) | gG/gL 80 A |
| Wiring (metric) | Solid/stranded: 1×2.5–35 mm² or 2×2.5–10 mm²; Ferruled: 1×1.5–25 mm² or 2×1.5–6 mm² |
| Wiring (AWG) | AWG 14–2 |
| Terminal Screw / Torque | M5 / 3 Nm (26.5 lb-in) |
| Ambient Temperature (enclosed) | −25 to +40 °C |
| Standards / Certifications | IEC/EN 60947-3, IEC/EN 60204, VDE 0660; UL, CSA; Declaration of CE Conformity available |
