Eaton / Moeller Series
40A, 4P, breaker, thermomagnetic, IEC
The Eaton/Moeller NZMN1-4-A40 is a molded case circuit breaker from the NZM1 (Frame 1) series, providing 40 A rated current across four poles. It features a thermomagnetic release adjustable from 32–40 A for overload protection and 320–400 A (8–10 × In) for short-circuit protection. Rated for up to 690 V operational voltage, it delivers breaking capacities of 85 kA at 240 V, 50 kA at 400/415 V, and 35 kA at 440 V. The breaker uses a rocker lever operator and fixed installation with box terminals (optional tunnel or rear connections). Offering IP20 basic protection (up to IP66 with accessories), it meets IEC/EN 60947 standards, is finger- and back-of-hand proof to VDE 0106, and supports rugged industrial use with 20,000 mechanical and 10,000 electrical operations. Operating reliably from −25 °C to +70 °C, the NZMN1-4-A40 ensures safe and durable system and cable protection.
Country of Origin: DE
We source directly from Eaton - 100% genuine, new-in-box certified parts.
| Brand | Eaton / Moeller |
|---|---|
| Series | NZM |
| Model | NZMN1-4-A40 |
| Catalog Number | 265811 |
| Product Type | Molded Case Circuit Breaker |
| Frame Type | NZM1 / Frame 1 |
| Trip Unit | Thermomagnetic release |
| Amperage Rating | 40 A (adjustable 32–40 A) |
| Short-Circuit Release | 320–400 A (8–10 × In) |
| Number of Poles | 4 |
| Operator | Rocker lever |
| Mounting | Fixed installation |
| Terminals | Box terminal (optional tunnel or rear) |
| Protection Against Contact | Finger and back-of-hand proof (VDE 0106) |
| Weight | — |
| Rated Insulation Voltage (Ui) | 690 V |
|---|---|
| Rated Operational Voltage (Ue) | 690 V AC |
| Impulse Withstand Voltage (Uimp) | 6 kV |
| Icu (Breaking Capacity) | 85 kA at 240 V; 50 kA at 400/415 V; 35 kA at 440 V; 20 kA at 525 V; 10 kA at 690 V |
| Ics (Service Capacity) | 85 kA at 240 V; 50 kA at 400/415 V; 35 kA at 440 V; 10 kA at 525 V; 7.5 kA at 690 V |
| Icm (Making Capacity) | 187 kA at 240 V; 105 kA at 400/415 V; 74 kA at 440 V; 40 kA at 525 V; 17 kA at 690 V |
| Utilization Category | A (IEC/EN 60947-2) |
| Power Loss (at In) | 10.66 W |
| Total Break Time | < 10 ms |
| Degree of Protection | IP20 (basic), IP40 with surround, IP66 with rotary handle |
| Ambient Operating Temp. | −25 °C to +70 °C |
| Mechanical Life | 20,000 operations |
| Electrical Life | 10,000 operations at 400/415 V; 7,500 at 690 V |
| Terminal Capacity (Cu wire) | 10–70 mm² stranded (up to 95 mm² depending on cable manufacturer) |
| Conductor Types | Copper or aluminum; busbar connection supported |
| Shock Resistance | 20 g (IEC 60068-2-27) |
| Climatic Proofing | Damp heat (IEC 60068-2-78, -2-30) |
| Certifications / Standards | IEC/EN 60947; VDE 0106; RoHS conform |
