Eaton / Moeller Series
250A, 3P, breaker, adjustable thermal-magnetic trip, IEC/UL
The Moeller NZMH2-VE250-BT-NA is a molded case circuit breaker from the NZM2 frame series, rated at 250A. It features an adjustable overload release with a setting range of 125–250A and a short-circuit release that provides both non-delayed (3000A) and delayed (250–2500A) protection. This 3-pole breaker is designed for selective protection and general industrial use, ensuring reliable overload and short-circuit protection. Built for use in demanding applications, it provides safe operation and compatibility with IEC/UL standards. Certification details are available from the manufacturer.
Country of Origin: DE
We source directly from Eaton - 100% genuine, new-in-box certified parts.
| Brand | Moeller |
|---|---|
| Model | NZMH2-VE250-BT-NA |
| Series | NZM2 |
| Product Type | Molded Case Circuit Breaker |
| Trip Type | Thermal-magnetic (adjustable overload + short-circuit release) |
| Amperage | 250A |
| Poles | 3 |
| Frame Size | NZM2 |
| Application | Selective and general protection |
| Rated Current (In/Iu) | 250A |
|---|---|
| Overload Release Range | 125–250A (Adjustable) |
| Short-Circuit Release (Non-Delayed) | 3000A |
| Short-Circuit Release (Delayed) | 250–2500A |
| Number of Poles | 3 |
| Trip Type | Thermal-magnetic |
| Certifications | IEC/UL (contact manufacturer) |
| Compliance | Meets IEC/UL standards |
