Eaton / Moeller Series
250A, 3P, breaker, thermomagnetic, UL/CSA/IEC
The Eaton NZMB2-S250-CNA is a 250A, 3-pole molded case circuit breaker with thermomagnetic release, designed for short-circuit protection in motor and feeder circuits. Built to meet UL, CSA, and IEC standards, it features a non-adjustable short-circuit release (8–10× In) and supports fixed mounting. With a rated operational voltage up to 440 V AC and insulation voltage of 690 V, it offers robust performance in industrial applications. The device includes screw terminals and supports multiple conductor types. Its rugged design includes IP20 protection and resistance to shock, UV, and corrosion.
Country of Origin: DE
We source directly from Eaton - 100% genuine, new-in-box certified parts.
| Brand | Eaton |
|---|---|
| Model | NZMB2-S250-CNA |
| Catalog Number | 102478 |
| Product Type | Circuit Breaker |
| Amperage | 250A |
| Poles | 3 |
| Trip Type | Thermomagnetic |
| Operator | Rocker Lever |
| Mounting | Fixed |
| Voltage Rating | 440 V AC |
|---|---|
| Insulation Voltage (Ui) | 690 V |
| Impulse Withstand Voltage (Uimp) | 8 kV (Main Contacts) |
| Short-Circuit Release Setting | 8–10× In |
| Short-Circuit Breaking Capacity (Icu @ 400V) | 25 kA |
| Short-Circuit Making Capacity (Icm @ 400V) | 53 kA |
| Connection Type | Screw Terminal |
| Degree of Protection | IP20 |
| Certifications | UL 489, CSA C22.2 No. 5-09, IEC 60947-2, CE |
| Ambient Operating Temperature | -25 °C to +70 °C |
