Eaton / Moeller Series
Klockner-Moeller NZM7-150-NA molded case disconnect switch, 150 amp, 3 pole, designed for manual, non-automatic switching applications. It provides no overcurrent protection and is intended strictly for use as a disconnect. Rated for continuous operation at full load and tested for motor circuit applications per NEC 430-109 and CEC 28-602. Operates at standard voltage levels with pressure wire terminals. UL (UL489) listed, CSA (C22.2 No. 5.2) certified, conforms to IEC/EN 60947-3 standards, and CE marked. Frame size 7.
We source directly from Eaton - 100% genuine, new-in-box certified parts.
| Model | NZM7-150-NA |
|---|---|
| Device Type | Molded Case Disconnect Switch |
| Amperage | 150A |
| Poles | 3 |
| Protection | Manual, Non-Automatic (No Overload or Short Circuit Protection) |
| Voltage Rating | Standard System Voltage (e.g. 480 Y / 277 V) |
| Wiring | Pressure Wire Terminals |
| Certifications | UL, CSA, IEC, CE |
| Standards Compliance | NEC 430-109, CEC 28-602, IEC/EN 60947-3 |
| Frame Size | 7 |
