Eaton / Moeller Series
Eaton NZM Undervoltage release, 110-130VAC, 0.091 kg, compliant with UL/CSA, IEC.
Eaton Moeller series NZM Undervoltage release, Catalog Number 259497, Model Code NZM2/3-XU110-130AC, EAN 4015082594978, suitable for NZM2(-4), N(S)2(-4), NZM3(-4), N(S)3(-4), complies with UL/CSA, IEC, RoHS standards, certified by CSA and UL.
Country of Origin: DE
We source directly from Eaton - 100% genuine, new-in-box certified parts.
| Specification | Value |
|---|---|
| Product Name | Eaton Moeller series NZM Undervoltage release |
| Catalog Number | 259497 |
| Model Code | NZM2/3-XU110-130AC |
| EAN | 4015082594978 |
| Used With | NZM2(-4), N(S)2(-4), NZM3(-4), N(S)3(-4) |
| Compliance | UL/CSA, IEC, RoHS conform |
| Certifications | CSA (Class No. 1437-01), UL489, CE marking |
| Global Catalog | 259497 |
| Specification | Value |
|---|---|
| Rated Control Supply Voltage | 110 - 130 V 50/60 Hz |
| Drop-Out Voltage of Undervoltage Release (AC/DC - MAX) | 0.7 x Us |
| Drop-Out Voltage of Undervoltage Release (AC/DC - MIN) | 0.35 x Us |
| Minimum Command Time - MAX | 15 ms |
| Minimum Command Time - MIN | 10 ms |
| Reaction Time | 19 ms |
| Pick-Up Power Consumption at AC (Undervoltage Release) | 1.5 VA |
| Pick-Up Power Consumption at DC (Undervoltage Release) | 0.8 W |
| Terminal Capacity (Solid/Flexible Conductor) | 18 - 14 AWG (1x), 0.75 mm² - 2.5 mm² (1x) |
