Eaton / Moeller Series
Eaton Moeller NZM Shunt release, 480-525VAC/DC, 42mm x 90mm x 30mm, 0.064kg
Eaton Moeller series NZM Shunt release (for power circuit breaker), 480-525VAC/DC. Catalog Number: 259768, Model Code: NZM2/3-XA480-525AC/DC, EAN: 4015082597689. Dimensions: Length 42 mm, Height 90 mm, Width 30 mm, Weight 0.064 kg.
Country of Origin: DE
We source directly from Eaton - 100% genuine, new-in-box certified parts.
| Specification | Value |
|---|---|
| Product Name | Eaton Moeller series NZM Shunt release |
| Catalog Number | 259768 |
| Model Code | NZM2/3-XA480-525AC/DC |
| EAN | 4015082597689 |
| Frame | NZM2/3 |
| Type | Accessory, Shunt release |
| Specification | Value |
|---|---|
| Rated Control Supply Voltage (US) at AC, 50 Hz - Max | 525 V |
| Rated Control Supply Voltage (US) at AC, 50 Hz - Min | 480 V |
| Rated Control Supply Voltage (US) at AC, 60 Hz - Max | 525 V |
| Rated Control Supply Voltage (US) at AC, 60 Hz - Min | 480 V |
| Rated Control Supply Voltage (US) at DC - Max | 525 V |
| Rated Control Supply Voltage (US) at DC - Min | 24 V |
| Number of Contacts (Normally Open Contacts) | 0 |
| Number of Contacts (Normally Closed Contacts) | 0 |
| Number of Contacts (Change-Over Contacts) | 0 |
| Undelayed Short-Circuit Release - Min | 0 A |
| Undelayed Short-Circuit Release - Max | 0 A |
Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
