Eaton / Moeller Series
Klockner-Moeller NZM10-400N/ZMVA-250-NA molded case circuit breaker 250 amp, 3 pole, fixed thermal trip 250A, adjustable magnetic trip 1000–9000A, with adjustable short-time delay pickup (2–12x Ir), system and cable protection, voltage 480 Y / 277 V, rated insulation voltage 690V, bolt-on connections line and load side, UL/CSA/IEC certified, frame size 10.
We source directly from Eaton - 100% genuine, new-in-box certified parts.
| Rated Current | 250A |
|---|---|
| Poles | 3 |
| Trip Type | Fixed Thermal / Adjustable Magnetic Inverse Time |
| Adjustable Magnetic Trip Range | 1000 – 9000A |
| Adjustable Short-Time Delay Pickup | 2 – 12 × Ir |
| Short-Time Delay Range | 0 – 1000 ms (Delayed) |
| System Voltage | 480 Y / 277 V |
| Rated Insulation Voltage | 690V |
| Terminals | Bolt-on (line and load side) |
| Certifications | UL, CSA, IEC |
| Frame Size | 10 |
