Eaton / Moeller Series
Undervoltage release, 24 V DC
Eaton Moeller series NZM Undervoltage release, Catalog Number 259547, Model Code NZM1-XUHIV24DC, rated for 24 V DC with two early-make auxiliary contacts. Complies with IEC, UL/CSA standards and is RoHS conform.
Country of Origin: DE
We source directly from Eaton - 100% genuine, new-in-box certified parts.
| Specification | Value |
|---|---|
| Product Name | Eaton Moeller series NZM Undervoltage release |
| Catalog Number | 259547 |
| Model Code | NZM1-XUHIV24DC |
| EAN | 4015082595470 |
| Compliance | IEC, UL/CSA, RoHS conform |
| Certifications | CE marking, IEC60947, CSA certified, UL (File No. E140305) |
| Specification | Value |
|---|---|
| Rated Control Supply Voltage | 24 V DC |
| Pick-Up Power Consumption at AC | 1.5 VA |
| Pick-Up Power Consumption at DC | 0.8 W |
| Drop-Out Voltage of Undervoltage Release (AC/DC - MAX) | 0.7 x Us |
| Drop-Out Voltage of Undervoltage Release (AC/DC - MIN) | 0.35 x Us |
| Minimum Command Time - MAX | 15 ms |
| Minimum Command Time - MIN | 10 ms |
| Reaction Time | 19 ms |
| Number of Normally Open Contacts | 2 |
| Terminal Capacity (Solid/Flexible Conductor) | 0.75 mm² - 2.5 mm² (1x) |
