Eaton / Moeller Series
4A, 3P, DOL motor starter, overload 1–4A, 24V DC coil, IE3-ready, IEC
The Eaton MSC-DEA-4-M7(24VDC) is a Direct-On-Line (DOL) motor starter rated for motors up to 1.5 kW at 400 V AC-3 applications. It includes a built-in thermal overload relay with a setting range of 1–4 A and a 24 V DC coil for actuation. Designed to meet IEC/EN 60947-4-1 standards, this device offers high short-circuit resistance with a rated Iq of 100 kA and coordination type “2”. It is suitable for IE3 motors and can be integrated with SmartWire-DT for communication when equipped with an additional module. The starter is preassembled with a PKE motor-protective circuit-breaker and a DILM7 contactor, offering compact protection and control for motor circuits.
Country of Origin: DE
We source directly from Eaton - 100% genuine, new-in-box certified parts.
| Brand | Eaton / Moeller |
|---|---|
| Model | MSC-DEA-4-M7(24VDC) |
| Series | MSC |
| Product Type | DOL Motor Starter |
| Old Part Number | MSC-DEA-4-M7(24VDC) |
| New Part Number | XTSEA004B007BTDNL |
| Starter Function | Direct-On-Line (DOL) |
| Poles | 3 |
| Overload Setting Range (Ir) | 1 – 4 A |
| Short-Circuit Release (Irm) | 168 A |
| Actuating Voltage | 24 V DC |
| Motor Rating (AC-3, 400 V) | 1.5 kW |
| Rated Operational Current (Ie) | 3.6 A |
| Motor Protection | Integrated with PKE breaker |
| Contactor Type | DILM7 |
| Mounting | Top-hat rail (adapter-less up to 15 A) |
| Rated Operational Voltage (Ue) | 230 – 415 V |
|---|---|
| Rated Impulse Withstand Voltage (Uimp) | 6000 V |
| Overvoltage Category / Pollution Degree | III / 3 |
| Short-Circuit Capacity (Iq) | 100 kA |
| Coordination Type | Type 2 |
| Power Consumption (Holding, DC) | 3 W |
| Voltage Type for Actuating | DC |
| Degree of Protection | IP20 |
| Bus Communication Ready | Yes (with PKE-SWD-32 module) |
| Connection Type | Screw Connection |
| Motor Ratings (Rated Current AC-3) |
0.18 kW – 1.04 A (220 V), 0.25 kW – 1.4 A (230 V), 0.37 kW – 2 A (240 V), 0.55 kW – 2.7 A (380–400 V), 0.75 kW – 3.2 A (380–400 V), 1.1 kW – 2.6 A (415 V), 1.5 kW – 3.6 A (415 V) |
| Standards Compliance | IEC/EN 60947-4-1, VDE 0660 |
| IE3 Motor Ready | Yes |
| SmartWire-DT Compatibility | Yes, with additional module |
| Thermal Protection | Yes (adjustable 1–4 A) |
| Mechanical Impact Rating | Device meets requirements |
| EMC Compliance | Panel builder responsibility |
| Insulation and UV Resistance | Meets standard requirements |
| Control Wiring Capacity | Max. 6 × 2.5 mm² or 4 × 3.5 mm² |
