Eaton / Moeller Series
0.2A, safety position switch, 12–30 V DC; 1NO+1NC, CE/ULCSA/IEC
Eaton Moeller® series LSE safety position switch model LSE-11, is a basic, expandable device with an electronically adjustable operating point. It features a plunger actuator with slow-action contacts (1 NO/1 NC), visual status indication, and robust IP66/IP67 protection. The unit operates on 12–30 V DC, supports up to 3,000 operations/hour, and is rated for 3,000,000 electrical and mechanical operations. It uses Cage Clamp terminals, withstands demanding EMC conditions (ESD, burst, surge), and is approved to CE, UL 508, CSA C22.2 No. 14, IEC/EN 60947-5, and IEC/EN 61000-4. Typical operating temperature range is −25 to +70 °C; enclosure is yellow, insulated plastic.
Country of Origin: DE
We source directly from Eaton - 100% genuine, new-in-box certified parts.
| Brand | Eaton Moeller® |
|---|---|
| Series | LSE |
| Catalog Number | 266121 |
| Model Code | LSE-11 |
| EAN | 4015082661212 |
| Product Type | Safety position switch |
| Actuator Type | Plunger |
| Switch Function Type | Slow-action switch |
| Contact Configuration | 1 NO, 1 NC |
| Status Indication | Visual |
| Enclosure | Plastic (insulated), Yellow cover, IP66/IP67 |
| Mounting Position | As required |
| Operating Frequency | 3000 operations/hour |
| Lifespan | 3,000,000 electrical / 3,000,000 mechanical operations |
| Ambient Operating Temperature | −25 to +70 °C |
| Dimensions (L × W × H) | 33.5 × 31 × 76.5 mm |
| Product Weight | 0.048 kg |
| Pollution Degree | 3 |
| Overvoltage Category | III |
| Operating Speed (DIN cam) | Max 1 m/s (α = 0°) / 0.5 m/s (α = 30°) |
| Suitable For | Safety functions |
| Rated Operational Voltage | 12–30 V DC |
|---|---|
| Rated Operational Current (DC-13, 24 V) | 0.2 A |
| Rated Breaking Capacity | 0.019 A (30 V DC) |
| Rated Switching Distance (Sn) | 0.5–5.5 mm |
| Switching Hysteresis | 0.4 % of Sn |
| ESD Immunity | 8 kV air / 4 kV contact (IEC/EN 61000-4-2, Level 3) |
| Burst Immunity | 2 kV (supply and signal cables, IEC/EN 61000-4-4, Level 3) |
| Surge Immunity | 0.5 kV (IEC/EN 61000-4-5) |
| EM Field Immunity | 10 V/m (IEC/EN 61000-4-3) |
| Conducted Immunity | 10 V (IEC/EN 61000-4-6) |
| Shock Resistance | 30 g, 20 ms half-sine (mechanical) |
| Temperature Resistance | 100 °C (roller head contact temperature) |
| Connection Type | Cage Clamp |
| Terminal Capacity (Flexible w/ Ferrule) | 1 × 0.5–1.5 mm² |
| Terminal Capacity (Solid) | 1 × 0.5–2.5 mm² |
| Degree of Protection | IP66/IP67; NEMA: Other |
| Certifications | CE; UL 508 (UL File E29184, Cat. NKCR); CSA C22.2 No. 14 (File 012528); IEC/EN 60947-5; IEC/EN 61000-4 |
