Eaton / Moeller Series
50A, 4P, breaker, fixed thermal magnetic, UL
The Eaton HFD4050 is a Series C molded case circuit breaker, built on the F-frame. Rated at 50 A across four poles, it uses a fixed thermal and magnetic trip unit (T186) to provide dependable overload and short-circuit protection. The breaker is rated for up to 600 Vac and 250 Vdc at 50/60 Hz and offers high interrupting capacities of 100 kAIC at 240 Vac and 65 kAIC at 480 Vac. With load-side terminals, compact dimensions of 6 × 5.5 × 3.38 in, and a weight of 4.5 lb, the breaker is UL Listed and backed by Eaton’s standard warranty. It provides reliable protection in commercial and industrial distribution systems.
Country of Origin: DO
HTS Code: 8536.20.0020
We source directly from Eaton - 100% genuine, new-in-box certified parts.
| Brand | Eaton |
|---|---|
| Series | Series C |
| Model | HFD4050 |
| Catalog Number | HFD4050 |
| Product Type | Molded Case Circuit Breaker |
| Frame Type | F-frame |
| Circuit Breaker Type | HFD |
| Trip Type | Fixed Thermal / Fixed Magnetic (T186) |
| Amperage Rating | 50 A |
| Number of Poles | 4 |
| Terminals | Load side |
| Dimensions (H × W × D) | 6 in × 5.5 in × 3.38 in |
| Weight | 4.5 lb |
| Voltage Rating | 600 Vac, 250 Vdc |
|---|---|
| Frequency Rating | 50/60 Hz |
| Interrupting Capacity | 100 kAIC at 240 Vac; 65 kAIC at 480 Vac |
| Certifications | UL Listed |
Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
