Eaton / Cutler-Hammer
80A, 3P, engine generator breaker, fixed magnetic pickup, UL 489/IEC 947-2
The Eaton FG3080 is a 3-pole, 80A thermal-magnetic circuit breaker specifically designed for engine generator applications. Built on the FG-frame, it features a fixed magnetic trip unit and is rated for up to 72 kVA at 600 VAC (60 Hz). The breaker supports reliable protection for generators with interrupting capacities of 18 kA at 240 VAC, 14 kA at 480 VAC, and 10 kA at 600 VAC per UL 489. It includes line and load terminals and complies with both UL 489 and IEC 947-2 standards, making it suitable for rugged generator installations in industrial environments.
Country of Origin: DE
We source directly from Eaton - 100% genuine, new-in-box certified parts.
| Brand | Eaton |
|---|---|
| Model | FG3080 |
| Series | FG |
| Product Type | Thermal-Magnetic Engine Generator Circuit Breaker |
| Frame Size | FG-Frame |
| Poles | 3 |
| Rated Current | 80 A |
| Trip Unit | Fixed Magnetic, Thermal-Magnetic |
| Terminals | Line and Load Included |
| Voltage Rating | 600 VAC, 50/60 Hz |
|---|---|
| Interrupting Capacity @ 240 VAC | 18,000 A |
| Interrupting Capacity @ 480 VAC | 14,000 A |
| Interrupting Capacity @ 600 VAC | 10,000 A |
| IEC Interrupting Capacity (240/415/690 VAC) | Up to 18,000 A / 14,000 A / 10,000 A |
| Generator Rating @ 240 VAC | 29 kVA / 23 kW |
| Generator Rating @ 480 VAC | 58 kVA / 46 kW |
| Generator Rating @ 600 VAC | 72 kVA / 58 kW |
| Compliance Standards | UL 489, IEC 947-2 |
| Weight | 15 lbs (7 kg) |
