Eaton / Moeller Series
6A, 3P, mini contactor, 24 V DC coil, 1 NO auxiliary contact, IEC/UL/CSA certified
The Eaton Moeller® Series DILEEM-10-G (24 V DC) Mini Contactor (Article No. 051643) is a compact 3-pole contactor rated for 6 A AC-3 duty, designed for reliable switching of motors and resistive loads up to 3 kW at 400 V. It includes one normally open (NO) auxiliary contact and screw-type terminals for secure wiring. Featuring a 24 V DC control coil, finger-safe IP20 terminals, and a mechanical endurance of 20 million operations, this contactor is ideal for industrial automation and control panels. Certified to IEC/EN 60947, UL 508, and CSA C22.2 No. 14-05 standards, it ensures dependable performance, electrical safety, and compatibility with IE3 motors.
Country of Origin: DE
We source directly from Eaton - 100% genuine, new-in-box certified parts.
| Brand | Eaton Moeller® Series |
|---|---|
| Model | DILEEM-10-G (24 V DC) |
| Article Number | 051643 |
| Product Type | Mini Contactor |
| Rated Operational Current (Ie) | 6 A (AC-3) |
| Poles | 3 |
| Control Voltage | 24 V DC |
| Auxiliary Contacts | 1 NO |
| Rated Operational Power (AC-3, 400 V) | 3 kW |
| Mounting Position | As required (except vertical with A1/A2 down) |
| Connection Type | Screw terminals |
| Degree of Protection | IP20 (Finger-safe) |
| Utilization Category | AC-3 / AC-1 / AC-4 |
|---|---|
| Rated Operational Voltage (Ue) | 690 V AC max |
| Rated Insulation Voltage (Ui) | 690 V AC |
| Rated Impulse Withstand Voltage (Uimp) | 6 kV |
| Conventional Thermal Current Ith (3-pole open @ 40 °C) | 22 A |
| Motor Rating (230 V AC) | 2 HP |
| Motor Rating (460 V AC) | 3 HP |
| Rated Power (AC-3, 230 V) | 1.8 kW |
| Rated Power (AC-3, 400 V) | 3 kW |
| Switching Frequency | 9000 mechanical operations/hour |
| Mechanical Life | 20 million operations |
| Ambient Temperature Range | −25 °C to +50 °C |
| Altitude Limit | 2000 m max |
| Short-Circuit Rating (SCCR) | 5 kA (UL/CSA) |
| Standards / Certifications | IEC/EN 60947-4-1, UL 508, CSA C22.2 No. 14-05, CE, VDE 0660 |
