Eaton / Moeller Series
1 early NO + 1 late NC, position switch, roller lever, slow-action, IP65, IEC/EN 60947
The Eaton Moeller AT4/11-2/I/R316 is a narrow-body position switch equipped with a roller lever actuator and slow-action contacts featuring one early-make normally open (NO) and one late-break normally closed (NC) contact. Designed for precision mechanical detection and industrial safety applications, it provides reliable switching and positive opening per IEC/EN 60947-5-1. The housing is dust-tight and water-protected (IP65) and made of durable insulated plastic, suitable for industrial environments. The actuator head can be rotated at 90° intervals to adapt to different approach directions. The unit complies with EN 50041 Form A, and is UL Listed, CSA Certified, and CE Marked for worldwide use.
Country of Origin: DE
We source directly from Eaton - 100% genuine, new-in-box certified parts.
| Brand | Eaton Moeller |
|---|---|
| Model | AT4/11-2/I/R316 |
| Catalog Number | 085926 |
| Product Type | Position Switch |
| Actuator Type | Roller Lever |
| Contact Configuration | 1 Early NO + 1 Late NC |
| Contact Type | Slow-action (Positive Opening) |
| Positive Opening Operation | Yes, IEC/EN 60947-5-1 |
| Housing Material | Insulated Plastic |
| Mounting Standard | EN 50041 Form A |
| Mounting Position | As required (head rotatable 90° intervals) |
| Basic Function | Position and Safety Position Switch |
| Degree of Protection | IP65 (use V-M20 cable glands, max. 9 mm thread length) |
|---|---|
| Rated Insulation Voltage (Ui) | 500 V |
| Impulse Withstand Voltage (Uimp) | 6000 V |
| Overvoltage Category / Pollution Degree | III / 3 |
| Rated Operational Current (AC-15, 24 V) | 10 A |
| Rated Operational Current (AC-15, 230 V) | 6 A |
| Rated Operational Current (AC-15, 400 V) | 4 A |
| Rated Operational Current (DC-13, 24 V) | 10 A |
| Rated Operational Current (DC-13, 110 V) | 1 A |
| Rated Operational Current (DC-13, 220 V) | 0.5 A |
| Thermal Current (Ith) | 10 A |
| Short-Circuit Protection | 6 A gG/gL Fuse |
| Rated Conditional Short-Circuit Current | 1 kA |
| Mechanical Life | 8 × 10⁶ operations |
| Repetition Accuracy | 0.02 mm |
| Operating Frequency | ≤ 6000 operations/hour |
| Actuating Force (Start/End of Stroke) | 8 N / 20 N |
| Actuating Torque (Rotary Drives) | 0.3 Nm |
| Max Operating Speed (DIN Cam) | 0.5 m/s (α = 0° / 30°) |
| Ambient Temperature Range | −25 °C to +70 °C |
| Contact Temperature (Max) | ≤ 100 °C |
| Terminal Capacity (Solid) | 1 × (0.75–2.5 mm²), 2 × (0.75–1.5 mm²) |
| Terminal Capacity (Flexible with Ferrule) | 1 × (0.5–1.5 mm²), 2 × (0.5–1.5 mm²) |
| Mechanical Shock Resistance | 5 g (standard-action) |
| Climatic Proofing | IEC 60068-2-78 / IEC 60068-2-30 (damp heat) |
| Design Verification | IEC/EN 61439 (thermal, corrosion, UV, and fire resistance) |
| Compliance Standards | IEC/EN 60947 | UL 508 | CSA-C22.2 No.14 | CE |
| Certifications | CE | UL Listed | CSA Certified |
| UL File No. | E29184 |
| CSA File No. | 12528 |
| UL/CSA Degree of Protection | UL: 1, 4X | CSA: 1, 3R, 4, 4X, 12, 13 |
