Eaton / Moeller Series
2N/C, position switch, rounded plunger, IP65, IEC/EN
The Eaton AT0-02-1-IA/ZS is a wide-enclosure position switch designed with a rounded plunger and center fixing for reliable mechanical operation. It features two normally closed (2 N/C) contacts with slow-action switching and includes a positive opening mechanism for safety applications. The device provides IP65 protection and up to 20 million mechanical operations, with screw terminal connections for secure wiring. Built with a durable insulated plastic housing, it operates within a temperature range of −25 °C to +70 °C and complies with IEC/EN 60947 and EN 50047 Form B standards, making it ideal for industrial automation and control environments.
Country of Origin: DE
We source directly from Eaton - 100% genuine, new-in-box certified parts.
| Brand | Eaton |
|---|---|
| Model | AT0-02-1-IA/ZS |
| Catalog Number | 021833 |
| Product Type | Position Switch |
| Enclosure Type | Wide, Centre Fixing |
| Actuator Type | Rounded Plunger |
| Contact Configuration | 2 N/C (Normally Closed) |
| Action Type | Slow Action |
| Mounting Position | As required |
| Connection Type | Screw Terminal |
| Enclosure Material | Insulated Plastic Housing |
| Enclosure Color | Grey |
| Degree of Protection | IP65 |
| Mechanical Life | 20 × 10⁶ operations |
| Positive Opening | Yes (IEC/EN 60947-5-1) |
| Suitable for Safety Functions | Yes |
| Rated Insulation Voltage (Ui) | 500 V AC |
|---|---|
| Rated Impulse Withstand Voltage (Uimp) | 6 kV |
| Rated Operational Current (AC-15 / 24 V) | 10 A |
| Rated Operational Current (AC-15 / 230 V) | 6 A |
| Rated Operational Current (AC-15 / 415 V) | 4 A |
| Rated Operational Current (DC-13 / 24 V) | 10 A |
| Rated Operational Current (DC-13 / 110 V) | 1 A |
| Rated Operational Current (DC-13 / 220 V) | 0.5 A |
| Short-Circuit Protection | 6 A gG/gL fuse (max) |
| Ambient Temperature Range | −25 °C to +70 °C |
| Repetition Accuracy | 0.02 mm |
| Actuating Force | 1.0 N (start) / 8.0 N (end) |
| Terminal Capacity (Solid) | 1 × (0.75–2.5 mm²) / 2 × (0.75–1.5 mm²) |
| Terminal Capacity (Flexible w/ Ferrule) | 1 × (0.5–1.5 mm²) / 2 × (0.5–1.5 mm²) |
| Supply Frequency | Max 400 Hz |
| Operating Frequency | ≤ 6000 operations/h |
| Protection Standard | IEC/EN 60947-5-1 |
| Environmental Tests | IEC 60068-2-78 / -2-30 (Damp Heat) |
