Eaton / Moeller Series
2NC, position switch, actuating rod, slow-action, IP65, IEC
The Eaton Moeller AT0-02-1-IA/H is a position switch with two normally closed (2NC) contacts and a spring actuating rod for flexible, multidirectional operation. It employs a slow-action, positive-opening contact mechanism in compliance with IEC/EN 60947-5-1, ensuring reliable disconnection of safety circuits. Its wide, insulated plastic housing provides robust electrical insulation and mechanical strength. Designed for industrial automation, this switch features IP65-rated protection for resistance against dust and moisture, offering dependable performance in harsh operating environments.
Country of Origin: DE
We source directly from Eaton - 100% genuine, new-in-box certified parts.
| Brand | Eaton Moeller |
|---|---|
| Model | AT0-02-1-IA/H |
| Catalog Number | 007595 |
| Product Type | Position Switch |
| Actuator Type | Spring Actuating Rod |
| Contact Configuration | 2NC |
| Contact Type | Slow-action (Positive Opening) |
| Housing Version | Wide Body |
| Housing Material | Insulated Plastic |
| Mounting Standard | EN 50047 |
| Mounting Position | Any |
| Degree of Protection | IP65 |
|---|---|
| Rated Insulation Voltage (Ui) | 500 V |
| Impulse Withstand Voltage (Uimp) | 6 kV |
| Rated Operational Current (AC-15, 24 V) | 10 A |
| Rated Operational Current (AC-15, 230 V) | 6 A |
| Rated Operational Current (AC-15, 400 V) | 4 A |
| Rated Operational Current (DC-13, 24 V) | 10 A |
| Rated Operational Current (DC-13, 110 V) | 1 A |
| Rated Operational Current (DC-13, 220 V) | 0.5 A |
| Thermal Current (Ith) | 10 A |
| Short-Circuit Protection | 6 A gG/gL Fuse |
| Repetition Accuracy | 0.02 mm |
| Mechanical Life | 20 × 10⁶ operations |
| Operating Frequency | ≤ 6000 operations/hour |
| Actuating Torque (Rotary Drives) | 0.2 Nm |
| Max Operating Speed (DIN Cam) | 1.5 m/s (L = 130 mm) |
| Contact Temperature (Max) | ≤ 100 °C |
| Ambient Temperature Range | −25 °C to +70 °C |
| Terminal Capacity (Solid) | 1 × (0.75–2.5 mm²), 2 × (0.75–1.5 mm²) |
| Terminal Capacity (Flexible with Ferrule) | 1 × (0.5–1.5 mm²), 2 × (0.5–1.5 mm²) |
| Mechanical Shock Resistance | 25 g (standard-action) |
| Climatic Proofing | IEC 60068-2-78 / IEC 60068-2-30 (damp heat) |
| Standards Compliance | IEC/EN 60947 | IEC/EN 61439 | EN 50047 | IEC 60068 |
| Certifications | CE |
