Eaton / Moeller Series
2NC, position switch, spring rod actuator, slow-action, IP65, IEC
The Eaton Moeller AT0-02-1-I/H is a position switch with two normally closed (2NC) contacts and a spring actuating rod that provides flexible, multi-directional operation. Designed for reliable mechanical position detection, it features a slow-action contact mechanism with positive opening operation, ensuring safe and consistent circuit interruption in accordance with IEC/EN 60947-5-1. Its wide insulated plastic housing offers high electrical insulation and IP65-rated protection, making it suitable for use in demanding industrial environments where precision, safety, and durability are required.
Country of Origin: DE
We source directly from Eaton - 100% genuine, new-in-box certified parts.
| Brand | Eaton |
|---|---|
| Model | AT0-02-1-I/H |
| Product Type | Position Switch |
| Actuator Type | Spring Rod Actuator |
| Contact Configuration | 2NC |
| Contact Type | Slow-action (Positive Opening) |
| Housing Version | Wide Body |
| Housing Material | Insulated Plastic |
| Mounting Standard | EN 50047 |
| Mounting Position | Any |
| Degree of Protection | IP65 |
|---|---|
| Rated Insulation Voltage (Ui) | 500 V |
| Impulse Withstand Voltage (Uimp) | 6 kV |
| Overvoltage Category / Pollution Degree | III / 3 |
| Rated Operational Current (AC-15) | 6 A @ 230 V AC |
| Rated Operational Current (DC-13) | 10 A @ 24 V DC |
| Thermal Current (Ith) | 10 A |
| Short-Circuit Protection | 6 A gG/gL Fuse |
| Mechanical Life | 20 × 10⁶ operations |
| Repetition Accuracy | 0.02 mm |
| Operating Frequency | ≤ 6000 operations/hour |
| Actuating Torque | 0.2 Nm |
| Ambient Temperature Range | −25 °C to +70 °C |
| Contact Temperature (Max) | ≤ 100 °C |
| Mechanical Shock Resistance | 25 g (standard-action) |
| Climatic Proofing | IEC 60068-2-78 / IEC 60068-2-30 (damp heat) |
| Standards Compliance | IEC/EN 60947 | EN 50047 | IEC 60068 |
| Certifications | CE |
