Eaton / Moeller Series
25A, 3P, control panel bus adapter, busbar mount with 20×5 mm Cu bar and 60 mm phase separation, IEC/UL/CSA compliant
The Moeller AD25/5-1 is a 3-pole control panel bus adapter designed for mounting in industrial control panels onto copper busbars of 20 × 5 mm with 60 mm phase separation. Rated for up to 25 A with 10 AWG supply leads and 54 mm adapter width, it allows quick and reliable connection of PKZM0 or PKZM0-/S(E)00 motor-protective circuit-breakers with AGM or NHI accessories. The adapter attaches directly to the bus at the rear while devices mount on top, with wiring to the supply leads. Installation must always be performed under de-energized (power-off) conditions for safety.
Country of Origin: DE
We source directly from Eaton - 100% genuine, new-in-box certified parts.
| Brand | Moeller |
|---|---|
| Product Name | Control Panel Bus Adapter |
| Model | AD25/5-1 |
| Article Number | AD25/5-1 |
| Product Type | Bus Adapter, 3-Pole |
| For Use With | PKZM0 or PKZM0-/S(E)00 with AGM or NHI |
| Adapter Width | 54 mm |
| Mounting | Cu busbar 20 × 5 mm, 60 mm phase separation |
| Included | 1 × AD25/5-1 Control Panel Bus Adapter |
| Maximum Rated Current | 25 A |
|---|---|
| Adapter Supply Leads | 10 AWG |
| Number of Poles | 3 |
| Connection Type | Rear bus connection with top-mounted devices |
| Operating Condition | Installation under de-energized (power-off) conditions |
| Certifications | IEC/EN, UL, CSA compliant |
