Eaton / Moeller Series
240V 60Hz, Shunt Release, screw terminals, AC actuation, UL/CSA/IEC/CE
The Eaton/Moeller A-PKZ0(240V60HZ) Shunt Release (new Eaton part number XTPAXSR240V60H) is an accessory module for motor-protective circuit breakers that provides remote tripping capability. Operating at 240 V AC 60 Hz, it is compatible with PKZM0, PKZM4, PKZM0-T, PKM0, PKZM01, and PKE breakers. This unit installs on the left-hand side of the breaker and uses screw terminals for simple wiring. With AC actuation, the shunt release requires 5 VA pull-in power and 3 VA sealing power. It is not compatible with the U-PKZ0 undervoltage release. Certified to UL 508, CSA C22.2 No.14, IEC 60947-4-1, and CE standards, the device ensures dependable performance and compliance with international requirements.
Country of Origin: DE
We source directly from Eaton - 100% genuine, new-in-box certified parts.
| Brand | Eaton / Moeller |
|---|---|
| Moeller Part Number | A-PKZ0(240V60HZ) |
| Eaton Part Number | XTPAXSR240V60H |
| Product Range | Accessories |
| Product Type | Shunt Release |
| For Use With | PKZM0, PKZM4, PKZM0-T, PKM0, PKZM01, PKE |
| Mounting | Left side of motor-protective circuit-breaker |
| Connection Technique | Screw terminals |
| Actuating Voltage | 240 V AC, 60 Hz |
|---|---|
| Voltage Type | AC (Standard Voltage) |
| Operating Range | 0.7 – 1.1 × Us |
| Pull-in Power | 5 VA |
| Sealing Power | 3 VA |
| Terminal Capacity (mm²) | 1 × (0.75 – 2.5) or 2 × (0.75 – 2.5) |
| Terminal Capacity (AWG) | 1 × (18 – 14) or 2 × (18 – 14) |
| Static Heat Dissipation | 0.5 W |
| Compliance Standards | UL 508, CSA-C22.2 No.14, IEC 60947-4-1, CE |
| UL File No. | E36332 |
| CSA File No. | 165628 |
| Certifications | UL Listed, CSA Certified, CE Marked |
| Not Compatible With | U-PKZ0 undervoltage release |
